Electric Rim Lock
- ModelRV900LC-L11
- Type
- Other
Operated by electricity, latchkey or hand Good security and protection because of release mechanism etc.; Electricity status: discontinuously supply current, power supply no more than 8 seconds; It's suitable for all sorts of access contro
l Features:
Ø Operated by electricity, latchkey or hand Good security and protection because of release mechanism etc.;
Ø Electricity status: discontinuously supply current, power supply no more than 8 seconds;
Ø It's suitable for all sorts of access controller system and door leaf;
Ø Pressure in normal:10000N
Ø High-Temperature Painted, Duable and Beautiful Article;
Ø Low Temperature, safe & Durable;
Ø MOV Provides Reverse Current Protection;
Ø Double protection for loading current;
l Parameters:
l Application
Ø Operated by electricity, latchkey or hand Good security and protection because of release mechanism etc.;
Ø Electricity status: discontinuously supply current, power supply no more than 8 seconds;
Ø It's suitable for all sorts of access controller system and door leaf;
Ø Pressure in normal:10000N
Ø High-Temperature Painted, Duable and Beautiful Article;
Ø Low Temperature, safe & Durable;
Ø MOV Provides Reverse Current Protection;
Ø Double protection for loading current;
l Parameters:
| Ø Type | Ø RV900LC-L11 |
| Ø Suitable For | Wooden Door, Metal Door |
| Ø Strike Structure | Zinc |
| Ø Life warranty | one year or 120,000 times operation |
| Ø Function | Built-out MOV |
| Ø Opening Mode | 90 Degree Swinging Door |
| Ø Voltage | 12VDC+10% |
| Ø Consumption Power | 8-10W |
| Ø Regulated and filtered voltage | 500VDC(one minute) |
| Ø Operating Temp | -40～+55℃(14-131F) |
| Ø Suitable Humidity | 0~90%(non-condensing) |
| Ø Lock Size | 130（L）X106（W）X40（H）mm±5％ |
| Ø Weight | 1.03 Kg±5％ |
l Application
